Rated Voltage | 36/38 kV |
Lightning impulse withstand voltage | 170 kV |
Power frequency withstand voltage | 80 kV |
Rated frequency | 56/60 Hz |
Internal arc class | AFLR |
Loss of service continuity category | LSC2B |
Earthing(ground) circuit | 31.5 kA – 3s |
External degree of protection | Available with IP4X |
Primary live parts (tank) degree of protection | IP65 |
Busbar rated current | 1250, 2000 ,2500A |
Busbar rated short-time withstand current | 31.5 kA – 3s |
Busbar rated peak withstand current | 82 kA |
Breaker rated short-time withstand current | 31.5 kA – 3s |
